Performance

• Acceleration (0-100 km/h): 4s
• Max speed: 230 km/h

---

Weight and Dimensions

• Length: 2850 mm
• Width: 1390 mm
• Height: 1205 mm
• Weight: 230 Kg

---

Chassis

• Typology: Tubular Space Frame
• Material: AISI 4130 steel
• Weight: 30 Kg

---

Dynamics

• Suspension Type: double wishbone pull-rod spring and damper actuated, and torsion bar
• Tyres: Avon A92 7,2/20-13
• Wheels: OZ Racing Magnesium CL
• Wheelbase: 1550 mm
• Front/rear track: 1200 mm / 1180 mm

---

Engine

• Typology: Yamaha FZ6 600cc, inline-4 cylinders
• Supply system: indirect electronic injection
• Engine Control Unit: MoTeC M84
• Max torque: 57,56 Nm @ 9000 rpm
• Max power: 61,85 Kw @ 9500 rpm

---

Drivetrain

• Gearbox: Yamaha 6-gear, sequential
• Gearbox actuation: manual lever
• Chain drive: #520
• Differential: Drexler LSD
• Final drive ratio: 3,69/1

---

Brake System

• Brake disks: steel, 220 mm diameter
• Callipers: Brembo P2,  2 pistons of 34 mm
• Master cylinder: AP Racing
